Ezcad design size is not same with red light show size & Marking size

February 21, 2020 /0 Comments/in /by

Solution of EZCAD Drawing size is not same with Red pointer size and Marking size

When we draw one square in EZCAD software of Laser Marking Machine,for example 100*100MM

The red line Show size is 90*80mm;Marking size is also 90*80mm.It is not same with ezcad drawing size.

Solution:

First click F3,Field,see following photo

Galvo2=X ,it is X axis cross axle

Galvo1=X ,it is Y axis vertical axis

First Choose Galvo 2=X,It mean corss axle(X axis) choose ,modify the Goal marking size into 100，Real Marking size is 90mm.Click Okay

Second Choose Galvo 1=X,It mean vertical axle(Y axis) choose ,modify the Goal marking size into 100，Real Marking size is 80mm.Click Okay

Then the parameter will be adjust well.

If you don’t modify the Galvo 1=X and Galvo 2=X parameter,pls don’t click Okay,just need click “Cancel”.It is important.

If you click okay,it will change the parameter auto,the red line,marking size will not correct again.
