How to install EZCAD software in new laptop?
How to install EZCAD software in New laptop?
Today we will share the steps of installing EZCAD software of laser marking machine.
5/5
First Step - EZCAD Software Install
1. Please copy the EZCAD software(software+driver file) from the USB flash or ask with supplier.
2.Send EzCad to desktop, as showninthe figure
3.You will see the corn at the desktop of your computer.
5/5
Secon Step - Control Card Driver Installation
1.Power on the machine, keep the control card be in “ReadyMode”.
2Connectthe computer with USB cable, then the computer will show “
”. Usually, you need to install the driver manually at the first time (The driver can not be installed well automatically).
3.Find “My Computer”, choose “Properties” and “Device Manager”, as shown in the figure
4.Choose “Other Devices” and you will see “USBLMCV2”, right-click to choose “Update Driver Software USBLMCV2”, as shown in the figure
5.Choose the path of Driver, as shown in the figure
install Driver
6.After finishing the driver installation, you will see “Laser Mark Control Board V2 [USB]” on “Device Manager”, as shown in the figure
Now, the Control Card Driver is installed well,the EZCAD software can be used well.
#EZCAD #LaserMarkingMachine #LaserEngravingMachine #FiberLaserMarkingMachine #LaserEngraver #LaserCutter #Laser #HowtoInstallEZCADSOftware
EZCAD Software show Can Not Find the LMC1 Drive?
EZCAD Software show Can Not Find the LMC1 Drive?
When open ezcad software,it show can’t find the LMC1 Driver.
Here are the solution to check this problem.
1) USB line problem, After the device is powered off, re-plug the cable and restart it; Or just change the USB line.
2) Software is broken. Delete all EzCad software in computer, copy new one and install the drive.
3) Control board is broken: After opening the hardware device manager, the hardware driver of the board cannot be found, there is no hardware prompt after re-plugging, or the prompt does not recognize the hardware. In this case, consider replacing the new board.
86 13854105019
86 13854105019
Skype
ChinaLindahao
sales@sismarlaser.com
#EZCAD #LaserMarkingMachine #FiberLaserMarkingMachine #UVLaserMarkingMachine #GreenLaserMarkingMachine #Co2LaserMarkingMachine #LaserMarking #LaserMarker #Laser #LaserEngraver #LaserCuttingMachine #LaserCutter
Fiber Laser Marking Machine’s Red dot is running, but no marking?
Red dot is running, but no marking?
5/5
Operation problem:
First, check if the material can absorb the 1064nm laser wavelength.
Second, if on the correct focus distance marking? What’s the output laser power? If it is bigger lens? Usually the laser will be weaker for bigger lens, also the depth of focus is relatively shallow, prone to this situation.
Third, check the marking content, if it is JPG or BMP format picture.
How to check on this situation? Use a piece of stainless steel, type TEXT, HATCH line distance is 0.05, laser power is 80%, speed is 500, chose Continue, then marking, up and down the marking head, will find where the problem from.
5/5
Parameter setting problem
Check the laser control model, if chose YAG model.
The laser control of fiber
The laser control of fiber
5/5
Laser source problem
If all the above 2 checked well, then will be laser source problem.
Fist, cut off the whole machine for 5 minutes, then reboot, if still can not mark, then need to check the laser source. Put the white dimming paper below the marking head, if can see the green laser spot. If can not, then laser source problem, further troubleshooting is required to resolve the problem either by laser failure or laser power failure
